- ALL NEW CABINET DESIGN
- YANMAR Powered
- YANMAR Reliability
- High Quality Brushless Alternator
- 11 kVA 240 Volt
- Water Cooled
- Silenced 60dB at 7 metres
- 3 × 15amp 240volt Outlets
- 1 x 32Amp 240volt Outlet
- Australian Compliant
- Full RCD & M.E.N. Wiring
- Easy connect ATS plug
- Remote Start Systems Available
- 2 YEARS OR 2,000 HOURS GENERATOR WARRANTY
Specifications
Powered by one of the most reliable Diesel engines in the world the YANMAR 3 Cylinder Diesel Engine 3TNV88-GGE with a high quality brushless 4 Pole alternator, this is one of the most cost-effective and high-performance generators you can buy!
Buy with peace of mind, ABLE’s range of Yanmar powered diesel generators are backed by 2 Years or 2,000 Hours Warranty.
Key Features:
- Reliable Engine: Equipped with reliable YANMAR 3 Cylinder Diesel Engine
- Robust Design: Tough-built, super-silenced canopy designed for outdoor.
- Watercooled: So it will run and withstands extremely hot conditions while it also extends the life of the engine over time.
- Stable Operation: 24 hours continuous stable power at prime load. Its low 1500 RPM engine generates a more stable operation.
- Silent Operation: 60 dBA at 7 metres, quieter than a normal conversation.
- Fuel efficiency: 2.7 Litres/Hour at prime load. Low fuel consumption. Low cost. A saving you can’t ignore!
- Highest Safety Standards: Australian Safety Standards compliant.
- 2 YEARS OR 2,000 HOURS YANMAR ENGINE WARRANTY
| Prime Power : | 10.0 kW / 10.0 kVA 240Volts 42Amps |
| Standby Power : | 11.0 kW / 11.0 kVA |
| Power Factor : | 1 |
| Phase Voltage : | Single Phase 240 Volt |
| Frequency : | 50 Hertz |
| Engine : | YANMAR 3 Cylinder Diesel 3TNV88-GGE |
| RPM : | 1500/min |
| Cooling Method : | Water Cooled - Rated For Australia's North |
| Alternator : | High Quality 4 Pole Brushless Synchronous -/c AVR |
| Starter System : | 12-volt Electric - Battery Included |
| Controller : | Comap MRS16 IL3/4 |
| 2 Wire / Remote Start Capable | |
| Over Temperature Protection | |
| Over Current Protection | |
| Low Oil Protection | |
| Safety Systems : | Battery Isolator |
| Emergency Stop | |
| Failsafe Shutdown Fuel Solenoid | |
| Noise Level : | 60 dBA at 7 metres |
| Fuel Tank Capacity : | 65 Litres (-/c Fuel Gauge) |
| Running Time : | 24 Hours Continuous (prime load) |
| Fuel Consumption : | 2.7 litres/hour (prime load) |
| Chassis Enclosure : | Lockable |
| Sound Deadening Throughout | |
| Weather-Resistant Powder Coating | |
| Stainless Steel Fittings | |
| External Use | |
| Mine Site Ready Bunding : | Yes |
| ATS (Mains Failure) : | Easy Connect Plug (ATS Box Optional) |
| Single Phase Outlets : | 3 x 15 Amp IP66 |
| 1 x 32Amp IP66 | |
| Three Phase Outlets : | No |
| No | |
| Hardwire Terminals : | Yes |
| RCD / RCBO : | Australian Standard (IP67 Enclosed) |
| Options : | Automatic Start Systems |
| GSM | |
| Timer | |
| Wireless Remote | |
| Solar System Compatible (Majority) | |
| ATS (Mains Failure Detection / Auto Transfer Switch) | |
| Minespec Padlockable Battery Isolator | |
| Weight : | 562kg |
| Dimensions : | 137 L x 73 W x 112 H cm |
