- Environmental Sealing
- Combined Power & Signal
- Compatible -/c ABLE ATS/AMF
- ISO9001
Specifications
| Number of Contacts : | 4 |
| Rated Current/Voltage : | 12A/150V |
| Maximum Voltage (AC.V.rms) : | 400 |
| Peak Voltage (AC.V.rms) 1 minute : | 1500 |
| Insulation Resistance (MΩ min) at DC 500V : | 2000 |
| Contact Resistance (MΩ max) at DC 1A : | 3 |
| Solder Cup Mouth Aperture (mm) : | 2 |
| Solder Internal Diametre (mm) : | 2.45 |
| Housing Exterior : | Copper / Zinc |
| Housing Interior : | Bakelite |
| IP Rating : | 67 |
| Dimensions LxWxH (mm) : | 35.5 x 18.5 x 18.5 |
| Weight (kg): | 0.01 |
| Options : | Socket |
| Shipping Weight : | 0.01 kg |
| Shipping Dimensions : | 5 L x 5 W x 5 H cm |
| Also Available : | ATS/AMF Box |
| Timer | |
| Countdown Timer | |
| Wireless Remote |
