Our 220kVA diesel generator won't give you any hassle. It runs 24 hours continuously at prime load and is tough-built to withstand extremely hot conditions in Australia's North and permanent outdoor use. Thanks to its tough, weather-proof canopy, battery insulation and water cooling method!
At its core is our time-proven reliable OEM 6 cylinder diesel turbo engine and the 4-pole brushless synchronous with AVR alternator outputting high-quality clean power. The ABLE 220kVA generator is popular for use in various commercial and industrial prime or backup power applications.
Key Features:
| Prime Power : | 160kW / 200kVA 415Volts 280Amps |
| Standby Power : | 176kW / 220kVA |
| Power Factor : | 0.8 |
| Phase Voltage : | Three Phase 415 Volt |
| Frequency : | 50 Hertz |
| Engine : | OEM 6 Cylinder Turbo Diesel |
| RPM : | 1500/min (Electronically Speed Controlled) |
| Cooling Method : | Water Cooled - Rated For Australia's North |
| Alternator : | Three Phase 4 Pole Brushless Synchronous -/c AVR |
| Starter System : | 24-volt Electric - Battery Included |
| Controller : | Comap MRS11 |
|
2 Wire / Remote Start Capable
|
|
|
Over Temperature Protection
|
|
|
Over Current Protection
|
|
|
Low Oil Protection
|
|
| Safety Systems : | Battery Isolator |
| Emergency Stop | |
| Failsafe Shutdown Fuel Solenoid | |
| Noise Level : | 67 dBA at 7 metres |
| Fuel Tank Capacity : | 950 Litres (-/c Fuel Gauge) |
| Running Time : | 20 Hours Continuous (prime load) |
| Fuel Consumption : | 48 litres/hour (prime load) |
| Chassis Enclosure : | Lockable |
| Sound Deadening Throughout | |
| Weather-Resistant Powder Coating | |
| Stainless Steel Fittings | |
| External Use | |
| Mine Site Ready Bunding : | Yes |
| ATS (Mains Failure) : | Easy Connect Plug (ATS Box Optional) |
| Single Phase Outlets : | 1 x 15 Amp IP66 |
| Three Phase Outlets : | 1 x 20 Amp IP66 |
| 2 x 32 Amp IP66 | |
| Hardwire Terminals : | Yes |
| RCD / RCBO : | Australian Standard (IP67 Enclosed) |
| Options : | Automatic Start Systems |
|
GSM
|
|
|
Timer
|
|
|
Wireless Remote
|
|
|
Solar System Compatible (Majority)
|
|
|
ATS (Mains Failure Detection / Auto Transfer Switch)
|
|
| Minespec Padlockable Battery Isolator | |
| Weight : | 2550 kg |
| Dimensions : | 320 L x 115 W x 215 H cm |
