Features:
• Fuel Cubes designed to meet ADR and UN Certification.
• Fuel Cubes Bunded to 110% of tank capacity
• Fuel Cubes constructed of mild steel
• Fuel Cubes pressure tested and hydrostatically tested
• Fuel Cubes baffled for safer transport.
Specifications
| Capacity: | 2,250 Litres |
| Safe Fill: | 2,000 Litres |
| Mounting Plate: | 580 x 970 mm |
| Dip / Filler | 1x 2" Lockable |
| Suction Port: | 3x 2" BSP |
| Return Port: | 3x 1-1/2: BSP |
| Extra Ports: | 1x 3" BSP |
| 4x 2" BSP | |
| Bund Vent: | 1x 2" BSP (Vent Included) |
| Breather Pipe: | 2x 2" BSP (650mm min Length Each) |
| Wet Weight: | 2785 kg |
| Dry Weight: | 870 kg |
| Dimensions: | 2,294 x 1,086 x 1,270 mm (LxWxH) |
Fork Lift pockets accessable on all Four Sides
