- Proven 192F 13HP Diesel Engine
- Easy Electric Start
- Idle Down System
- Reliable and Proven Air End
- 145PSI Maximum Pressure
- 130PSI Working Pressure
- 30CFM Continuous Reliable Airflow
Specifications
| Engine type: | 192F 13HP Single Cylinder, 4-stroke, Air-cooled, Diesel Engine |
| Horse Power/rpm: | 13 HP 1,500 - 3,000 RPM |
| Starting system: | Electric/Recoil, Battery included |
| Rotation direction: | Clockwise, (View from flywheel) |
| Engine Lube: | SAE15W40 (above CC grade) |
| Battery: | With 12V-20Ah |
| Compressor: | 30CFM Screw Compressor |
| Compressor Maximum Pressure: | 145 PSI / 10 BAR |
| Compressor Working Pressure: | 130 PSI / 9 BAR |
| Compressor Drive: | Triple V-Belt Drive |
| Compressor RPM: | 6,000 RPM |
| Pressure Gauge: | Oil filled pressure gauge MPA |
| Air Receiver: | 4L Buffer Tank |
| Noise Level: | 80dB @ Idle / 90dB During Operation |
| Air Outlets: | 1 × 1/2" Outlet |
| Total Weight: | 266 kg |
| Dimensions: | 110 x 83 x 82 cm (L x W x H) - (110 x 83 x 96 cm with Wheels) |
| Carton Total Weight: | 280 kg |
| Carton Dimensions : | 120 x 93 x 100cm (L x W x H) |
